The Tycon Power TP-POE-HP-48GD POE Injector is a high-quality Power Over Ethernet (POE) power source designed for reliable and efficient operation in demanding environments. This robust midspan injector is specifically engineered to provide seamless power and data connectivity to remote devices over Ethernet cables, ensuring your network remains robust and uninterrupted. Whether you’re powering IP cameras, VoIP phones, or wireless access points, this POE injector meets all your power delivery needs with exceptional performance and safety features.

• Reliable Performance: Built to operate under severe conditions, the TP-POE-HP-48GD guarantees consistent power delivery even in the most challenging environments, making it ideal for industrial and outdoor applications.
• Surge Protection: This injector features comprehensive surge protection, safeguarding your devices from electrical overstress and ensuring reliable operation without damage.
• High Power Output: With a power output of up to 50W, the TP-POE-HP-48GD is perfect for high-demand devices, offering versatility in powering anything from surveillance cameras to high-performance wireless access points.
• Wide Voltage Range: The TP-POE-HP-48GD operates on a wide AC input range of 90VAC to 264VAC (50/60 Hz), making it compatible with various power sources and ensuring smooth functionality across different environments.
• Multiple Output Options: This model provides flexible output configurations with 18V, 24V, and 48-56V DC output options, allowing users to select the most suitable voltage for their devices with a load regulation within 5%.

Technical Details of the TP-POE-HP-48GD POE Injector

• Input Voltage: 90VAC to 264VAC (50/60 Hz)
• Output Voltage: 18V, 24V, or 48-56V DC
• Power Output: Up to 50W
• Ethernet Compatibility: Supports 802.3af, 802.3at, and Gigabit Ethernet
• Protection Features: Surge protection, short circuit protection, overload protection, and overvoltage protection
• Distance Capability: Supports up to 100m (328 feet)
• LED Indicator: Current sense LED that indicates power status when a POE device is connected

How to Install the TP-POE-HP-48GD POE Injector

Installing the TP-POE-HP-48GD is straightforward and user-friendly. Follow these simple steps for a successful installation:

1. Connect the input power source to the injector's AC input terminal.
2. Use a shielded RJ45 Ethernet cable to connect the data-in port of the injector to your network switch or router.
3. Connect another RJ45 Ethernet cable from the data-out port of the injector to the POE-enabled device you wish to power.
4. If using the CI model, ensure that the current sense LED is functioning by checking the indicator light.
5. Power on your injector, and your devices will receive both data and power through the Ethernet cable.

Frequently Asked Questions

• Q: Can the TP-POE-HP-48GD power devices that require 802.3af and 802.3at?
  A: Yes, the TP-POE-HP-48GD is compatible with devices that support both the 802.3af and 802.3at standards, providing flexibility in powering various devices.
• Q: What is the maximum distance that the POE injector can transmit power?
  A: The TP-POE-HP-48GD can transmit power and data over Ethernet cables for distances up to 100m (328 feet), ensuring wide coverage for your devices.
• Q: Is the TP-POE-HP-48GD safe to use in outdoor settings?
  A: Yes, this injector is designed for reliable performance under various environmental conditions, including outdoor settings, as long as it is housed in a weatherproof enclosure.
• Q: Can I use this injector with non-POE devices?
  A: The TP-POE-HP-48GD is specifically designed for POE devices. Connecting non-POE devices may not provide power and could damage the injector or the device.
• Q: Does the injector require any special configuration before use?
  A: No special configuration is needed. Simply install it following the installation steps, and it will automatically provide power and data to compatible devices.
